Mini Geotechnical Drill Rigs
Rotary Auger Drill, SPT Autohammer, CPT & DMT Testing, Shelby Tube Sampling and Direct Push Geotechnical Soil Test Drill Rigs
Starting at
$79,950
Our SPT drilling and soil investigation platforms are specifically designed for geotechnical engineering. These platforms are compact but powerful and can be mounted on a trailer, in a truck or on our traditional rubber tracks.
-
MA-23 Rotary Drill Mast and SPT Autohammer
On Tracks $82,500
Truck/Trailer $79,950
- Drill head:YMT-500 single speed (200 rpm, 974 ft lbs of torque)
- 23 hp (17 kW) - gasoline engine, air-cooled
- 10 gpm (37 lpm) max hydraulic flow
- Autohammer 140lb (63.5 kg) - Conforms to ASTM D-1586-11 for SPT sampling
- Winch
- Chain mast with 2,300 lbs lift force
- Mount: Rubber tracks, trailer or truck
-
MB-23 Rotary Drill, SPT Autohammer and Auger Drilling
On Tracks $92,950
Truck/Trailer $89,950
- 23 hp (17 kW) - gasoline engine, air-cooled
- 20 gpm (37 lpm) max hydraulic flow
- Autohammer 140lb (63.5 kg) - Conforms to ASTM D-1586-11 for SPT sampling
- Winch
- High force extraction cylinders with 20,000 lbs lift force
- Mount: Rubber tracks, trailer or truck
- Drill head options:
- AGR two speed (100-200 rpm, 3500 ft lbs of torque)
- MRA two speed (100-200 rpm, 3500 ft lbs of torque)
- YMT-500 single speed (200 rpm, 974 ft lbs of torque)
- SA3 single speed (20 rpm, 3500 ft lbs of torque)
- SA5 single speed (18 rpm, 5200 ft lbs of torque)
-
MC-23 Rotary Drill & Auger Drilling, SPT Autohammer, CPT & DMT
On Tracks $115,500
Truck/Trailer $109,500
- 23 hp (17 kW) - gasoline engine, air-cooled
- 20 gpm (37 lpm) max hydraulic flow
- Autohammer 140lb (63.5 kg) - Conforms to ASTM D-1586-11 for SPT sampling
- Winch
- High force extraction cylinders with 56,000 lbs lift force
- Mount: Rubber tracks, trailer or truck
- Drill head options:
- AGR two speed (100-200 rpm, 3500 ft lbs of torque)
- MRA two speed (100-200 rpm, 3500 ft lbs of torque)
- YMT-500 single speed (200 rpm, 974 ft lbs of torque)
- SA3 single speed (20 rpm, 3500 ft lbs of torque)
- SA5 single speed (18 rpm, 5200 ft lbs of torque)
-
MCX-38 Rotary Drill & Auger Drilling, SPT Autohammer, CPT & DMT
On Tracks $128,000
- 38 hp (28 kW) - gasoline engine, electronic fuel injected
- 20 gpm (37 lpm) max hydraulic flow
- Autohammer 140lb (63.5 kg) - Conforms to ASTM D-1586-11 for SPT sampling
- Winch
- High force extraction cylinders with 56,000 lbs lift force
- Mount: Rubber tracks, trailer or truck
- Drill head options:
- AGR two speed (100-200 rpm, 3500 ft lbs of torque)
- MRA two speed (100-200 rpm, 3500 ft lbs of torque)
- YMT-500 single speed (200 rpm, 974 ft lbs of torque)
- SA3 single speed (20 rpm, 3500 ft lbs of torque)
- SA5 single speed (18 rpm, 5200 ft lbs of torque)
